The WING Compact is the smaller sibling of the WING and runs the same mixing engine. It offers a full live console with motorized faders and a touchscreen in a size that fits smaller stages and control positions.
Key features and typical uses
- 48 FlexChannels and 28 buses with full stereo architecture
- 16 motorized 100 mm faders and a 10.1" multi-touch display
- 24 Midas PRO mic preamps and 8 outputs on board
- 3 AES50 ports for up to 144 inputs/outputs
- Can be installed in a 19-inch rack
- Suited to bands, conferences, theatre and corporate events
| Channels | 48 FlexChannels |
|---|---|
| Mic preamps | 24 Midas PRO |
| Outputs (analog) | 8 |
| Faders | 16 motorized (100 mm) |
| AES50 ports | 3 (up to 144 I/O) |
| Display | 10.1" multi-touch |
| Power consumption | 130 W |
| Dimensions (W x H x D) | 57.4 x 22.5 x 45.3 cm |
| Weight | 15.9 kg |
